OLED Panel (Organic Light Emitting Diodes)
Simulates a 40" screen at 2 meters distance
16:9 Aspect Ratio
2 x High resolution panels with 870 x 500 pixels each panel.
24 Bit RGB color
Field of view (FOV): 30°
Supports 3D
Side-by-side / Top-Bottom / Line interleaved
Frame Packing via HDMI (720p / 1080p)
Diopter Adjustment
Diopter adjustment from -5 to +2 D on each eye
Interpupillary Distance (IPD)
The optics support an IPD range of 59 – 69mm
Input sources
HDMI: 720p, 1080p and 3D (Frame Packing)
Plays Video from iPod & iPhone via an optional accessory.
AV-In: 3.5mm jack / 4-pin jack for audio & video (PAL/NTSC)
External connectors
Mini-USB for charging the built-in rechargeable battery
3.5mm audio jack connector for external headphones
Light source
LED-Class 1
Power supply
Internal rechargeable lithium-ion battery.
Charges via USB; 5 V / 450 mA
Battery life: about 6 hours fully charged
Charging time 2.5 hours
Weight
Battery pack: 60 g, HDMI adapter 30 g
Approx weight on nose. 75 g
Video glasses approx. 120 g
Environmental conditions
Operating temperature: 5 °C to 35 °C
Storage and transport: –20 °C to 45 °C
Humidity 10–80%, non-condensing
