The new DYS XS20A  ESCs are specially designed for high KV power racing motors. The small size and integrated solder pads make for a cleaner and easier installation and are matched perfectly with the new DYS MR2205-2750KV brushless racing motors.

Feature: Silabs EFM8BB2 50MHz MCU, Oneshot125/Oneshot42/Multishot enabled

Features

• XS series ESC is the upgraded version of the XM series with advanced processor, a basic frequency up to 50MHz, and faster overall processing capacity to better support high KV motors

• Designed for quick multi-rotor throttle response

• Twisted pair cable is used to deliver throttle signal, reducing signal crosstalk while further stabilizing copper wire transmission

• New miniaturization and ultra-low resistance MOSFET, powerful flow resistance, and professional MOS Drive chips improve efficiency

• Newly designed PCB board improves impact resistance.

• Sub-miniaturization design reduces weight while still providing a high performance filtering capacitor

• Refresh rate of throttle signal up to 500Hz, compatible with all modern flight controllers, including the Naze32 Rev6 and SP Racing F3

• Ultra-high speed Oneshot125 with 3000Hz refresh rate provides quick, smooth throttle response

• Fully programmable via USB port, with two-way and 3D modes for high speed racing and acrobatics.
