Simplified power with ECOS

The ELite is the first FrSky radio to feature the all-new ECOS operating system. It’s designed to provide a more intuitive learning curve and a faster, streamlined setup. While ECOS inherits the powerful look and feel of ETHOS, it achieves a significant level of simplification. This allows users new to RC – across various application scenarios to enjoy a complete and user-friendly experience while keeping both budget and the learning curve to a minimum.

Robust Connectivity & Wide Expansion Options

The ELite integrates a powerful 2.4GHz internal RF module, enabling direct pairing with ACCST D16 or ACCESS receivers. This ensures reliable, low-latency control performance right out of the box.

Portable Design & Versatile Options

Built to be lightweight and portable. Combined with a comprehensive array of hardware inputs, including multi-position switches and momentary buttons, the ELite fully meets the requirements of fundamental flight scenarios while offering broad expandability.

Features:

- Integrated ECOS operating system with built-in 2 .4G ISRM internal RF module

- Supports ACCST D16/ACCESS protocols

▪ Low-latency (＜4ms) supporting full telemetry

▪ Less latency capability with high reliability at a faster data rate

- Ergonomic and compact lightweight design with game controller-type grip design

- Top switch buttons within easy reach

- 128×64 resolution backlit monochrome display

- 2×5D joystick navigation buttons & M1/M2 function buttons

- 2×3-position switches, 1×latching button, and 1×momentary switch

- Equipped with potentiometer gimbals

- LED indicator system shows battery status

- 4000mAh 1S Li-ion battery for long operating time

- Supports USB Type-C charging

- Supports wired training system via DSC port

Specs:

Dimensión: 170,4×122,6×70,4 mm (L×W×H)

Weight: 255g (Battery Incl.)

Operating System: ECOS

Internal RF Module: ISRM-L

Screen Resolution: 128×64

Number of Channels: Up to 24 Channels

Operating Voltage Range: 3.3V ~ 4.2V (1S Li-Battery)

Operating Current: 100mA@3.7V (typ.)

Operating Temperature: -10℃ ~ 60℃ (14℉~140℉)

Battery Bay Size: 65×40×11.6mm (L×W×H)

USB Adaptor Voltage and Current: 5V+0.2V, ≥2.0A

Compatibility: ACCST D16 / ACCESS
