Matek RGB LED Board 5050 16V comes with three RGB5050 LEDs & one code switch. Seven colors are selectable by means of code switches. This LED board gives an eye-catching effect to your multirotors or planes when illuminated.
Specifications:INPUT: 14~17V DC
Size: 47*10mm
Weight: 2g
Packing: LED BOARD 16V, 1pcs, Cable 0.3m
Notes:
Comes with a 0.3m long cable, users can cut it to a suitable length;
Be ware of the positive and negative poles, as well as the insulation;
Switch the related codes to ON, seven colors are selectable;
The input is in a range of 14~17V DC, can be powered by 4S Lipo
Selectable Colors & Power:- B ON =Blue, 0.4W, 25mA
- R ON =Red, 0.4W, 25mA
- G ON =Green, 0.4W, 25mA
- B+R =Megenta, 0.8W, 50mA
- B+G =Cyan, 0.8W, 50mA
- R+G =Yellow, 0.8W, 50mA
- B+R+G =White, 1.2W, 75mA
